Air Slide Fabric is woven from wear-resistant and high-temperature resistant fibers. At the same time, the design of the Air Slide Fabric takes into account the nature of the conveyed material, adapts to different conveying angles and distances, improves its applicability and flexibility, ensures that the material will not be damaged or contaminated during the conveying process, and adapts to the special working conditions of different industries.
Air Slide Fabric is a device that supports the material and allows air to evenly penetrate and fluidize the material. The chute Air Slide Fabric is mainly used for air conveying chute, homogenization silo inflatable box and silo bottom breathable layer. The product is laid between the material and the air chamber, with the air chamber below and the material above. Under the action of air pressure, the air flow passes through the product to fluidize the material, thereby achieving the purpose of conveying.
The multi-layer structure of the Air Slide Fabric for the chute has different weights, thicknesses and permeabilities, which can make the flow effect of the sliding surface uniform, have greater mechanical wear resistance and tensile strength, and have a wide range of porosity.
Maintenance and repair process of Air Slide Fabric for chute
- Shutdown → disconnection → lock → confirm.
- Remove the shell bolts → remove the shell → remove the bolts at both ends of the Air Slide Fabric → remove the Air Slide Fabric.
- Install a new Air Slide Fabric: lay the Air Slide Fabric on the chute and align one end and the side → apply silicone glue on the end plate → cover the end pressure plate → use the gas cutter to punch holes in the breathable layer with a red-hot 8mm steel bar → fix this end with bolts → use the plywood and manual hoist to straighten and fix the breathable layer at the other end → install the shell sealant and rubber pad → use the red-hot steel bar to drill holes on both sides → - assemble the bolts and tighten.
- Clean the site → notify the operator to start the fan or air compressor → use soapy water to check for leaks → confirm.
Conclusion
The Air Slide Fabric is an important device that supports materials, allows air to evenly penetrate and fluidize materials, and is mainly used in pneumatic conveying chute for powder materials such as cement and alumina.
